High Temperature Industrial Cable

Silicone Steel Braided Control Cable

Extreme Heat Resistance • Heavy Mechanical Protection • Built for Steel Mills
Designed for environments where conventional PVC cables become brittle due to extreme temperature fluctuations, this Silicone Steel Braided Control Cable delivers outstanding performance in demanding industrial applications. Featuring silicone rubber insulation, a durable silicone outer sheath, protective glass fibre braiding and galvanized steel wire armour, it provides exceptional resistance to heat, oil, ozone, oxidation and mechanical damage. During fire exposure, the silicone insulation forms a protective silicon dioxide layer around the conductor, helping maintain circuit integrity and reducing the risk of short circuits.

✔ Key Benefits

  • Excellent heat resistance from -60°C to +180°C
  • Short circuit temperature up to +200°C
  • Ideal for steel works and foundries
  • Outstanding resistance to oils and fats
  • Resistant to oxygen and ozone
  • Fire-resistant silicone insulation
  • Heavy-duty galvanized steel wire armour
  • Excellent mechanical protection
  • Long service life in harsh environments

⚙ Technical Specifications

Conductor Tinned Copper Class 5
Standard VDE 0295 Class 5
Core Insulation Silicone Rubber
Outer Sheath Silicone Rubber (Red-Brown)
Protection Glass Fibre Braiding
Armour Galvanized Steel Wire Braid
Temperature Range -60°C to +180°C
Short Circuit Up to +200°C
Bending Radius 20 × Cable Diameter
Applications Steel Works, Foundries, Rolling Mills, Metallurgical Plants & High-Temperature Industrial Equipment
Engineered for Extreme Heat • Reinforced for Maximum Protection • Trusted in Heavy Industry
