Medium Voltage Power Cable with Fibre Optic

TRATOSFLEX® ES + Fibre Optic

Medium Voltage Power • Integrated Fibre Optic • Built for Critical Industrial Applications
TRATOSFLEX® ES is a premium medium-voltage power cable designed for the most demanding industrial applications. Combining highly flexible tinned copper conductors with integrated fibre optic communication, HEPR rubber insulation and a heavy-duty 5GM3 rubber sheath, it provides outstanding electrical performance, reduced cable dimensions and exceptional mechanical durability. Its advanced extruded semiconductive screen ensures uniform electrical stress distribution, while anti-torsional protection makes it ideal for cable reels, mining equipment, port cranes and heavy industrial machinery where both power and data transmission are required.

✔ Key Benefits

  • Integrated fibre optic communication
  • Reduced cable weight and overall dimensions
  • Advanced extruded semiconductive screen
  • Highly flexible tinned copper conductors
  • Reduced halogen construction
  • Excellent resistance to mechanical stress
  • Anti-torsional protection for dynamic applications
  • Suitable for cable reels and mobile equipment
  • Reliable power and data transmission in one cable

⚙ Technical Specifications

Model TRATOSFLEX® ES (TSCGEWOU + LWL)
Standards VDE 0250 & HD 620 S1
Rated Voltage 3.6/6 • 6/10 • 8.7/15 • 12/20 kV
Maximum Voltage 7.2 • 12 • 18 • 24 kV AC
AC Test Voltage 11 • 17 • 24 • 32 kV
Conductor Tinned Copper (Extra Flexible)
Insulation HEPR with Extruded Semiconductive Screen
Ground Conductor Semiconductive Layer
Communication Integrated Optical Fibre Cable
Outer Sheath 5GM3 Red Rubber with Anti-Torsional Protection
